Products
Showing 1-10 of 22 items
| SKU | Design | Spring force start | Max. stroke | Cylinder pipe diameter | Piston rod diameter | Length | |
|---|---|---|---|---|---|---|---|
| 2484.12.01500.025 | with valve | 1500 daN | 25 mm | 75.2 mm | 36 mm | 160 mm | |
| 2484.12.01500.025.P | without valve | 1500 daN | 25 mm | 75.2 mm | 36 mm | 160 mm | |
| 2484.12.01500.038 | with valve | 1500 daN | 38.1 mm | 75.2 mm | 36 mm | 186.2 mm | |
| 2484.12.01500.038.P | without valve | 1500 daN | 38.1 mm | 75.2 mm | 36 mm | 186.2 mm | |
| 2484.12.01500.050 | with valve | 1500 daN | 50 mm | 75.2 mm | 36 mm | 210 mm | |
| 2484.12.01500.050.P | without valve | 1500 daN | 50 mm | 75.2 mm | 36 mm | 210 mm | |
| 2484.12.01500.063 | with valve | 1500 daN | 63.5 mm | 75.2 mm | 36 mm | 237 mm | |
| 2484.12.01500.063.P | without valve | 1500 daN | 63.5 mm | 75.2 mm | 36 mm | 237 mm | |
| 2484.12.01500.080 | with valve | 1500 daN | 80 mm | 75.2 mm | 36 mm | 270 mm | |
| 2484.12.01500.080.P | without valve | 1500 daN | 80 mm | 75.2 mm | 36 mm | 270 mm | |
| 2484.12.01500.100 | with valve | 1500 daN | 100 mm | 75.2 mm | 36 mm | 310 mm | |
| 2484.12.01500.100.P | without valve | 1500 daN | 100 mm | 75.2 mm | 36 mm | 310 mm | |
| 2484.12.01500.125 | with valve | 1500 daN | 125 mm | 75.2 mm | 36 mm | 360 mm | |
| 2484.12.01500.125.P | without valve | 1500 daN | 125 mm | 75.2 mm | 36 mm | 360 mm | |
| 2484.12.01500.160 | with valve | 1500 daN | 160 mm | 75.2 mm | 36 mm | 430 mm | |
| 2484.12.01500.160.P | without valve | 1500 daN | 160 mm | 75.2 mm | 36 mm | 430 mm | |
| 2484.12.01500.200 | with valve | 1500 daN | 200 mm | 75.2 mm | 36 mm | 510 mm | |
| 2484.12.01500.200.P | without valve | 1500 daN | 200 mm | 75.2 mm | 36 mm | 510 mm | |
| 2484.12.01500.250 | with valve | 1500 daN | 250 mm | 75.2 mm | 36 mm | 610 mm | |
| 2484.12.01500.250.P | without valve | 1500 daN | 250 mm | 75.2 mm | 36 mm | 610 mm | |
| 2484.12.01500.300 | with valve | 1500 daN | 300 mm | 75.2 mm | 36 mm | 710 mm | |
| 2484.12.01500.300.P | without valve | 1500 daN | 300 mm | 75.2 mm | 36 mm | 710 mm |
