Products
Showing 1-10 of 5 items
| SKU | Spring force start | Max. stroke | Cylinder pipe diameter | Piston rod diameter | Length | |
|---|---|---|---|---|---|---|
| 2486.12.03000.125 | 3000 daN | 125 mm | 120.2 mm | 50 mm | 390 mm | |
| 2486.12.03000.160 | 3000 daN | 160 mm | 120.2 mm | 50 mm | 460 mm | |
| 2486.12.03000.200 | 3000 daN | 200 mm | 120.2 mm | 50 mm | 540 mm | |
| 2486.12.03000.250 | 3000 daN | 250 mm | 120.2 mm | 50 mm | 640 mm | |
| 2486.12.03000.300 | 3000 daN | 300 mm | 120.2 mm | 50 mm | 740 mm |
