Products
Showing 1-10 of 5 items
| SKU | Spring force start | Max. stroke | Cylinder pipe diameter | Piston rod diameter | Length | |
|---|---|---|---|---|---|---|
| 2486.12.05000.125 | 5000 daN | 125 mm | 150.2 mm | 65 mm | 405 mm | |
| 2486.12.05000.160 | 5000 daN | 160 mm | 150.2 mm | 65 mm | 475 mm | |
| 2486.12.05000.200 | 5000 daN | 200 mm | 150.2 mm | 65 mm | 555 mm | |
| 2486.12.05000.250 | 5000 daN | 250 mm | 150.2 mm | 65 mm | 655 mm | |
| 2486.12.05000.300 | 5000 daN | 300 mm | 150.2 mm | 65 mm | 755 mm |
