Products
Showing 1-10 of 4 items
| SKU | Spring force start | Max. stroke | Cylinder pipe diameter | Piston rod diameter | Length | |
|---|---|---|---|---|---|---|
| 2496.12.00270.016 | 270 daN | 16 mm | 38 mm | 22 mm | 108 mm | |
| 2496.12.00270.025 | 270 daN | 25 mm | 38 mm | 22 mm | 126 mm | |
| 2496.12.00270.050 | 270 daN | 50 mm | 38 mm | 22 mm | 176 mm | |
| 2496.12.00270.080 | 270 daN | 80 mm | 38 mm | 22 mm | 236 mm |
