Products
Showing 1-10 of 7 items
| SKU | Spring force start | Max. stroke | Cylinder pipe diameter | Piston rod diameter | Length | |
|---|---|---|---|---|---|---|
| 2497.12.00500.010 | 500 daN | 10 mm | 32 mm | 18 mm | 75 mm | |
| 2497.12.00500.015 | 500 daN | 15 mm | 32 mm | 18 mm | 85 mm | |
| 2497.12.00500.025 | 500 daN | 25 mm | 32 mm | 18 mm | 105 mm | |
| 2497.12.00500.038 | 500 daN | 38 mm | 32 mm | 18 mm | 130 mm | |
| 2497.12.00500.050 | 500 daN | 50 mm | 32 mm | 18 mm | 155 mm | |
| 2497.12.00500.063 | 500 daN | 63 mm | 32 mm | 18 mm | 190 mm | |
| 2497.12.00500.080 | 500 daN | 80 mm | 32 mm | 18 mm | 225 mm |
