Products
Showing 1-10 of 7 items
| SKU | Spring force start | Max. stroke | Cylinder pipe diameter | Piston rod diameter | Length | |
|---|---|---|---|---|---|---|
| 2497.12.01000.010 | 1000 daN | 10 mm | 38 mm | 25 mm | 75 mm | |
| 2497.12.01000.015 | 1000 daN | 15 mm | 38 mm | 25 mm | 85 mm | |
| 2497.12.01000.025 | 1000 daN | 25 mm | 38 mm | 25 mm | 105 mm | |
| 2497.12.01000.038 | 1000 daN | 38 mm | 38 mm | 25 mm | 135 mm | |
| 2497.12.01000.050 | 1000 daN | 50 mm | 38 mm | 25 mm | 160 mm | |
| 2497.12.01000.063 | 1000 daN | 63 mm | 38 mm | 25 mm | 205 mm | |
| 2497.12.01000.080 | 1000 daN | 80 mm | 38 mm | 25 mm | 240 mm |
